Parameter |
Unit |
Value |
|
系统外形尺寸 System overall size |
mm |
1033*770*555 |
|
产品净重 Product net weight |
kg |
258 |
|
额定输出功率 Rated output power |
kW |
132 |
|
电堆体积功率密度 Volume power density of stack |
kW/L |
3.6 |
|
系统质量功率密度 Mass power density of system |
W/kg |
511.6 |
|
低温启动温度 Low-temperature start temperature |
℃ |
-30℃ |
|
工作环境温度Working ambient temperature |
℃ |
-30℃~60℃ |
|
防护等级 Protection level |
IP |
IP67 |
|
产品优势： 全球首个单堆系统额定功率突破130kW; 联合研发大功率DCDC; 电堆功率密度超过3.6kW/L; 新型故障诊断与健康管理策略; 寿命达到15000小时以上; 可实现-30℃的正常启动; |
Product advantages:The rated powerof system exceeded 132kW;
Joint research and development of high-power DCDC; The power density of the stack exceeds 3.6 kW/L; New fault diagnosis and management strategy; The service life is more than 15000 hours; Normal startup at – 30℃ can be realized; |
|
Post time: Jan-09-2023
