10kW Liquid-cooled fuel cell system

10kW Liquid-cooled fuel cell system Featured Image
  • 10kW Liquid-cooled fuel cell system
  • 10kW Liquid-cooled fuel cell system
  • 10kW Liquid-cooled fuel cell system
  • 10kW Liquid-cooled fuel cell system

Short Description:

Over the years, passed ISO 9001:2015 international quality management system, we have gathered a group of experienced and innovative industry talents and R & D teams, and have rich practical experience in product design and engineering applications. we can customize the fuel cell according to each our customer’s requirements.

10kW water-cooled fuel cell system is independently developed by our company and is mainly used for all kinds of backup power, 5G base station, emergency power supply and distributed power station. Different powers can be customized according to customer needs.

The system is highly integrated, with good durability, strong stability, high flexibility and environmental protection. It has the advantages of reasonable design, high power density, fast start-up speed, strong environmental adaptability, convenient maintenance and so on.


Download as PDF

Product Detail

Product Tags

1.Product Introduction
Liquid cooling has been generally and efficiently utilized in the high power PEMFC stacks (>5 kW), the thermal properties (specific heat capacity, thermal conductivity) of liquid are several orders higher than gas or air so for higher cooling load of the stack, liquid as a coolant is a natural choice instead of air. Liquid cooling via separate cooling channels is used in the PEM fuel cell stacks which are mainly used for higher power fuel cell.

10kW liquid-cooled hydrogen fuel cell stack can produce 10kW of nominal power and brings you full energy independence for various applications that require power in the range of 0-10kW.

2

2. Product Parameter

Parameters for water-cooled 10kW Fuel Cell System

Output performance		 Rated power 10kW
Output voltage DC 80V
Efficiency ≥40%
 Fuel Hydrogen purity ≥99.99%（CO＜ 1PPM)
Hydrogen pressure 0.5-1.2bar
Hydrogen consumption 160L/min
Working condition Ambient temperature -5-40℃
Ambient humidity 10%～95%


Stack characteristics

 Bipolar plate Graphite
Cooling medium Water-cooled
Single cells Qty 65pcs
Durability ≥10000 hours
Physical parameter Stack Size (L*W*H) 480mm*175mm*240mm
Weight 30kg

3.Product Feature And Application

Product features:

Ultra thin plate

Long service life and durability

High power density

High speed voltage inspection

Automatic bulk production.

Water-cooled fuel cell stack can be customized acoording to customer’s need.

Applications:

Automobiles, drones and forklifts provide power

Outdoors are used as portable power sources and mobile power sources

Backup power sources in homes, offices, power stations, and factories.

Use wind power or hydrogen stored in the sun.

3

Fuel cell stack constructure:

4



Over the years, passed ISO 9001:2015 international quality management system, we have gathered a group of experienced and innovative industry talents and R & D teams, and have rich practical experience in product design and engineering applications. we can customize the fuel cell according to each our customer’s requirements.
